Spring isolators can be used for: generator sets, power supplies, industrial fans and air-handling units.
- High strength all steel construction epoxy powder coated finish with B.Z.P fixings as standard.
- Optional Stainless steel fixings available.
- Colour coded helical steel springs to BS1726 Class B with nominal deflections of 25 mm and 50 mm and up to 50% overload capacity.
- Vertical and lateral restraints have rubber inserts to avoid metallic contact and adequate radial clearance ensures isolation efficiency is not impaired.
- Springs located and seated on rubber washers to reduce high frequency transmission.
- Working height and vertical limiting stops are fully adjustable.
- 6 mm thick ribbed rubber seating pad supplied as standard.
Typical Applications
- Cooling Towers.
- Chillers.
- Large Fans.
- Air Handling Units.
